Sacrificial anode

Graphite itself is not directly employed as a sacrificial anode material, but it may participate in or influence the performance of sacrificial anodes in an indirect manner within cathodic protection systems. Here is a detailed analysis:

1. Fundamental Principles of Sacrificial Anodes

Sacrificial anodes protect metallic structures (such as steel, pipelines, etc.) through electrochemical corrosion (self-dissolution). The commonly used materials need to meet the following criteria:

  • High Reactivity: They should possess a lower electrode potential than the protected metal (e.g., magnesium, zinc, aluminum, and their alloys).

  • High Current Efficiency: The corrosion products should not readily passivate and should be capable of continuous discharge.

  • Low Cost and Environmental Friendliness.

2. Conflicts Between Graphite's Properties and Sacrificial Anode Requirements

  • Conductivity but Chemical Inertness: Graphite exhibits good electrical conductivity but high chemical stability (with a relatively high electrode potential, close to +0.5 V vs. SHE). Thus, it cannot serve as an active anode material.

  • Cathodic Behavior: In electrochemical systems, graphite often functions as an inert cathode (such as in fuel cell electrodes) and cannot provide protective current through self-dissolution.

3. Potential Roles of Graphite in Sacrificial Anode Systems

Although graphite is not used as an anode material, it may appear in the following scenarios:

(1) Auxiliary Conductive Components

In cathodic protection systems, graphite may be utilized as a grounding material or conductive filler to facilitate current distribution. However, it must be used in conjunction with active anodes (such as magnesium anodes).

(2) Composite Anode Materials (Research Field)

A few studies have attempted to combine graphene or carbon materials with active metals (such as zinc and aluminum) to enhance the conductivity and corrosion uniformity of anodes. In these cases, graphite merely serves as an additive, with the active metal remaining the primary component.

4. Practical Sacrificial Anode Materials

  • Magnesium and Magnesium Alloys: Used in high-resistivity environments (such as soil and freshwater).

  • Zinc and Zinc Alloys: Suitable for seawater or low-resistivity environments.

  • Aluminum Alloys: Commonly used in marine environments due to their relatively low cost.

5. Alternative Roles of Graphite

In impressed current cathodic protection (ICCP) systems, graphite can function as:

  • Inert Anodes: Under the action of an impressed current, graphite can assist in conductivity but does not dissolve itself (requiring an external power source, which differs from the principle of sacrificial anodes).
